Invacare® LiNX
10–way Switch
A C E G I
B D F H J
If the stand function is available for your power wheelchair, buttons G and H are used to operate the stand function.
A Recline down
B Recline up
4.16.3 Speed Reduction and Seating Function Inhibits
The mentioned speed reduction and seating function inhibits do not apply to all Invacare wheelchair models.
Driving Function Inhibits
Drive Lockout
l
Drive lockout (DLO) is a function to prevent the wheelchair from
being driven when the seat tilt or recline are beyond a pre-
determined safe total angle. The total angle can be any
combination of seat angle, recline and / or surface angle. For most
of the Invacare wheelchair models, Drive lockout only responds
when you adjust angles in standstill. AVIVA RX makes an
exception: Drive lockout also responds while driving.
According to that, an icon is displayed in the status bar. This
indicator remains active until Drive lockout is deactivated by
adjusting seat angle and backrest angle.
56
1. Make sure power wheelchair is on level surface and turned o n.
2. Press and hold button to move particular seating function.
Seating function moves as long as button is pressed.
C Seat lifter up E Left or central legrest up G
D Seat lifter down
F
Left or central legrest
H
down
Speed Reduction
l
If the seat lifter or the seat angle has been adjusted above a
certain point, the drive electronics considerably reduces the speed
of the wheelchair. If speed reduction has been activated, drive
mode can only be used to carry out movements in reduced speed
and not for regular driving. To drive normally, adjust the lifter or
the seat angle until the speed reduction is deactivated again.
Speed reduction is shown in the display. If the seat lifter or the
seat angle is raised above a certain point, the above icon is
displayed in the status bar. This indicator remains active until
speed reduction is deactivated again by lowering the lifter.
Right l egrest up /
I Seat tilt up
Stand function up
Right l egrest down /
J Seat tilt down
Stand function down
1637423-K
