4–way Toggle Switch
A
1. Make sure power wheelchair is on level surface and turned on.
2. Deflect and hold toggle switch to direction, that moves particular seating function.
D
C
B
Seat Tilt and Recline
Seat tilt up
A (Forward)
Seat tilt down
B (Reverse)
Recline up
C (Left)
Recline down
D (Right)
Seat Tilt and Seat Lifter
Seat tilt up
A (Forward)
Seat tilt down
B (Reverse)
Seat lifter up
C (Left)
Seat lifter down
D (Right)
54
Seating function moves as long as toggle switch is deflected.
See tables below for combinations of directions and powered seating functions.
The tables shows the factory settings. For reprogramming, contact your provider.
Seat Tilt and LNX Legrest
A (Forward)
B (Reverse)
C (Left)
D (Right)
Both Legrests
A (Forward)
B (Reverse)
C (Left)
D (Right)
Recline and LNX Legrest
Seat tilt up A (Forward)
Seat tilt down
B (Reverse)
LNX up C (Left)
LNX down D (Right)
Stand Function and Seat Lifter
Left l egrest up
A (Forward)
Left legrest down
B (Reverse)
Right legrest up
C (Left)
Right legrest down
D (Right)
Recline and LNX up
Recline and LNX down
LNX up
LNX down
Stand function up
Stand function down
Seat lifter up
Seat lifter down
