Invacare® LiNX
By default, latched driving mode is pre-set in combination with
a Sip and Puff only and with a Sip and Puff Head Array. For all
other types of control, latched driving mode is not a default
set-up but can be enabled by your provider.
Each drive function can be assigned with a latched
driving mode by your provider. There are six latched
driving modes, which are indicated on the lower left
of the drive card with the symbols displayed in the
table below.
1 Step Up
3 Step Up
5 Step Up
The Latch Drive Timeout period is restarted whenever a
subsequent drive demand is given.
The Latch Drive Timeout is set by the provider. To change the
parameter, contact your provider.
38
3 Step Up/Down
5 Step Up/Down
Cruise Control
Turn Demands
The wheelchair can be steered while in latched driving mode. If a turn
demand is given, the wheelchair remains in latched driving mode and
also responses to the turn demand for the duration that the turn
demand is given. The Latch Drive Timeout period is restarted
whenever a turn demand is given. When the Latch Drive Timeout
expires, the wheelchairs stops.
4.10.1 External Stop Switch
To set up a wheelchair for latched driving, an external stop switch
must be fitted to the wheelchair. Ideally, the external stop switch
should be highly visible and easily accessible to provide an extra level
of safety and security for the user.
External Stop Switch Test
The external stop switch test checks that the external stop switch is
functioning correctly. The test is conducted once per power cycle
when:
the wheelchair is powered up in a latched drive mode function or
l
a latched drive mode function is selected following a non-latched
l
mode function.
The external stop switch test is indicated by a
screen overlay.
1. Press external stop switch to complete test.
The wheelchair does not drive until the
external stop switch test is completed
successfully.
