4.6 Using the Multipurpose Keys
A B
By default, you can change profiles and function cards with
the multipurpose keys.
1. Press left key A to switch to next profile.
2. Press right key B to switch to next function card.
4.7 Using the Toggle Switches (Optional)
The toggle switches are an alternative means to switch commonly-
used controls and can be an option for users who, for example have
difficulties to reach the ON/OFF key, multipurpose keys or struggle to
operate certain areas of the touch screen of the remote.
A
When the switches are deflected forwards or
C
backwards from the neutral position, the
B
programmed action is performed. If the
D
switches are released, the switches return to
the neutral position.
1637423-K
By default, the following actions are performed:
A Forward command
Left Backwards command (short
toggle press)
B
switch
Backwards command (long
press)
Right
C Forward command
toggle
D Backwards command
switch
4.8 Proportional / Discrete Driving Mode
4.8.1 Using Joystick
The joystick controls the direction and speed of the wheelchair.
When the joystick is deflected from the neutral
(centre) position, the wheelchair moves in the
direction of the joystick movement.
If the joystick is released from any position
other than the neutral position, the joystick
returns to the neutral position and the
wheelchair slows down and stops.
The joystick can also be used to wake up the
system when in sleep mode, if this parameter
has been enabled by your provider, refer to
4.15 The Sleep Mode, page 50.
4 Usage
Power button (On / Off)
switch to next function card
Switch to next profile
Increase speed by 10 %
Decrease speed by 10 %
