4.21.10 Using the Wireless Mouse Emulator
1. Turn on the Bluetooth on your proton box by pressing an external switch until you hear a long beep.
2. Connect the Wireless Mouse Emulator via the USB port with your computer.
3. Mouse emulator and Head Array connect automatically.
4. Default set up is:
Back pad:
l
Mouse moves up and down
Mouse movement and behaviour can be changed via the switches at the back of the Wireless Mouse Emulator.
A
This is a slower speed initially for precise targeting. It is set and used in conjunction with Cursor Delay to give the user the ability to move the
mouse slowly at first and then speed up after a set amount of time to move across the screen efficiently.
B
This setting controls the maximum speed of the cursor and is the speed that the mouse will obtain after the initial speed. Note: The base
speed is set in the control panel of the computer's mouse settings.
C
1637423-K
Right pad:
l
Mouse moves left and right
Dip switch 1 & 2: Initial mouse movement
slow
Dip switch 3 & 4: Maximum cursor or mouse speed
disabled
Dip switch 5 & 6: Cursor delay
disabled
medium slow
2x base
1.0 sec
A CDEF G B
Left pad:
l
select
medium fast
4x base
2.0 sec
4 Usage
fast
8x base
4.0 sec
