Changing Function Cards
For difference between function card and profile, refer to 2.2.3 User Function Card Overview, page 8.
1. Short press mode switch to change function card.
2. Long press mode switch to change profile.
4.21.8 Using the Four Switch Proximity Array
WARNING!
Risk of serious injury
Proximity sensors are sensitive to water. If enough water is present close to sensors, they may be activated and power wheelchair may
start moving unintentionally.
— Do not operate Four Switch Proximity Array in wet weather.
— Do not operate Four Switch Proximity Array in any circumstances where water may come close to sensors.
The Four Switch Proximity Array is a three-quadrant operation. The Four Switch Proximity Array offers four proximity sensors that allow to operate
a power wheelchair or change the function cards. The sensors are activated, as soon as an input comes within 6 mm of the sensors.
By default, the sensors power up as soon as the wheelchair is powered up and power down as soon as the wheelchair is powered down.
Be aware, that when powering up automatically with the wheelchair, you must not cover the proximity sensors, otherwise a
drive OON warning is displayed and prevents the wheelchair from driving. For more information about OON, refer to 6.2
OON ("Out Of Neutral"), page 93.
The picture below shows a configuration example in combination with an Eclipse Tray. For individual adjustment, contact your provider.
1637423-K
Seating functions can only be operated with the right or left p ad
of the head array.
