Invacare® LiNX
B C
D
Indicators for forward and reverse are shown in the display.
Forward drive function card
To revolve, you only need to cover sensors A or C.
4.21.9 Using the Remote Stop Switch
The Remote Stop Switch allows a wheelchair to be stopped within a range of approximately six meters (20 feet).
1. Press the STOP button A to stop wheelchair.
B
2. Press GO button B to allow wheelchair to move again.
In case you lose the remote and the wheelchair cannot be operated, disconnect the jack plug of the Remote Stop Switch box
from the power module.
84
1. Cover sensor B to drive forwards.
2. To drive in reverse, cover sensor D to change direction.
Cover sensor B to drive in reverse.
3. Cover sensors A and B to veer to the left.
4. Cover sensors C and B to veer to the right.
5. Cover sensor D to change function card.
Forward active Reverse drive function card Reverse active
