4.10.2 1 Step Up
In this mode, a single drive demand (forward or reverse) causes the wheelchair speed to accelerate to the maximum drive
A
speed A of the selected drive card and then remain at that speed for the programmed Latch Drive Timeout period as long as no
further demand is given.
Accelerating
1. Give drive demand in desired direction (forward or reverse).
2. Release drive demand. Wheelchair speed accelerates to maximum drive speed of the selected drive card.
Decelerating
When stopping, the speed decelerates to zero at one of two rates (normal or gentle), depending on how the deceleration is triggered (long or
short demand) and if the optional slower rate is configured by the provider.
Normal Rate
1. Give long drive demand, greater than one second, in opposite
direction (a reverse demand when driving forwards or a forward
demand w hen driving in reverse) or
press external stop switch.
Interrupting Deceleration
When stopping (except for an emergency stop or control input configured for a stop), the deceleration can be interrupted to resume driving.
1. Give drive demand for accelerating before speed has reached zero, so speed accelerates to maximum drive speed of the selected drive card.
1637423-K
Gentler Rate
1. Give short drive demand, less than one second, in opposite
direction (a reverse demand when driving forwards or a forward
demand when driving in reverse) or
let Latch Drive Timeout expire.
