4–way Button Switch
A
1. Make sure power wheelchair is on level surface and turned on.
2. Press and hold button to move particular seating function.
B
Seating function moves as long as button is pressed.
C
See tables below for combination of buttons and powered seating functions.
D
The tables shows the factory settings. For reprogramming, contact your provider.
Seat Tilt and Recline
Seat tilt up
A
Seat tilt down
B
Recline up
C
Recline down
D
Seat Tilt and Seat Lifter
Seat tilt up
A
Seat tilt down
B
Seat lifter up
C
Seat lifter down
D
1637423-K
Seat Tilt and LNX Legrest
A Seat tilt up
Seat tilt down
B
C LNX up
D LNX down
Both Legrests
Left l egrest up
A
Left legrest down
B
Right legrest up
C
Right legrest down
D
Recline and LNX Legrest
Recline and LNX up
A
Recline and LNX down
B
LNX up
C
LNX down
D
Stand Function and Seat Lifter
Stand function up
A
Stand function down
B
Seat lifter up
C
Seat lifter down
D
