5 Control Panel Instructions
Details of each item are shown below:
Multiple Origins Enable
Set Origin 1/2/3/4
Next Origin
Origin Enable 1/2/3/4
The system can use multiple different origins. If you select Take the Original
Origin as the Origin, the work started for each time will use different origins.
The rotation order of origin is 1 → 2 → 3 → 4 → 1 → 2... If the processing file is
uploaded to the PC and this file selects Take the Current Origin as the Origin,
the system will always use the current origin.
Yes or No can be selected. If you select No, the system will use single-
origin settings. You can press
Yes, the system will use the multiple-origin settings and
keyboard becomes invalid. In this case, the parameter of each origin
must be set in the menu as follows.
After the multiple-origin setting is enabled, put the cursor on Set as
Origin 1/2/3/4. Press
coordinates as the corresponding ones of the origin 1/2/3/4.
Users can choose from 0−4, which represent the origins to be used
for the next figure. Origin 0 refers to the origin set by
single-origin setting. 1−4 represent the origins under the multiple-origin
setting. The next origin can be chosen from origin 1−4 so as to control
the starting point of the next job. However, it cannot be changed to
origin 0.
After the multiple-origin setting is enabled, the four origins can also be
individually disabled and enabled.
67
and set the origin. If you select
on the keyboard and the system will take the
on the
under the
