Button Description
Returns the machine to the saved default parameters.
Manually fires the laser.
Sets the speed of the current running layer or of the direction keys' movement.
Sets the minimum laser power of the current running layer.
Sets the maximum laser power of the current running layer or sets the power of
the laser.
Opens the file control menu.
Starts or pauses the work.
Moves the laser head along the X axis or the left/right cursor.
Moves the laser head along the Z or U axis if Z Move or U Move in the function
menu has been selected.
Moves the laser head along the Y axis or the up/down cursor.
Opens the function menu.
Stops work or exits from a submenu.
Enters a command or confirms your selection.
Sets the starting point for the laser head.
Traces the outline of the current design for sizing.
