5 Control Panel Instructions

5.4.4 Resetting the Axes

When Axis Reset+ is selected, push
Push or to select an item. Press
start the resetting of the selected axis, and the
message "Resetting Is Underway" will show on
the screen. Upon completion, the message will
automatically disappear and the system will
return to the main interface.

5.4.5 Adjusting the Laser Movement Mode

When Manual Set+ is selected, press
When Mode is selected, push
choose between the two modes Continue and
Manual. Push to move the cursor. When the
cursor is on Manual, push
to change the parameters. If the continuous
mode is selected, release this button and the
laser stops. If the continuous mode is selected
when is pressed, the laser head will move
continuously as long as the direction arrows are
held down. If the manual mode is selected, each
time the direction arrows are pressed, the laser
head will move by precisely the distance shown
beside Manual in this screen.
and the display will show:
to
and the following will be displayed:
or to
or and or
