5.4 Function Menu

5.4.1

Function Interface

Press on the main interface to enter the Function interface, as shown below:
Push or tto select an item, and then push to enter the corresponding submenu.

5.4.2 Adjusting the Z Axis

When Z Move is selected, push
or to control the movement of the Z axis when a motorized
workbed (sold separately) is installed.

5.4.3 Adjusting the U Axis

When U Move is selected, push or to control the movement of the U axis. This can be used to
control the rotational position of a rotary axis or the linear position of an automatic feed (both sold
separately) if either is installed.
64
