3 Installation

3.2 Unpacking

Your engraver should have arrived in a wooden crate with its accessories (including this manual)
packaged in the main bay. You should have placed the crate in a spacious flat area for unpacking,
ideally near where you plan to operate the machine permanently. Use at least two people to move
and adjust the engraver's position to help keep it level and avoid any sharp or sudden movement.
1. Remove the crate from around your engraver, and remove the surrounding foam insulation.
2. Each foot is attached to the base of the crate with a hex
screw. Use a 7.8 mm hex wrench to remove them.
3. Rotate the feet up, unlock the wheels, and roll the machine into place.
4. Fix it in place by pressing down on the brake pads on the 2 front wheels and rotate the feet
down to anchor them. If needed, suitable fasteners can also be used with the 0.2 inch (5 mm)
holes to further secure your engraver.
5. Open the cover in the front of the machine and take out the accessories pack placed on the
workbed.
Make sure that you have received all listed accessories in the package list (See
List on Page 13).
6. CAREFULLY remove the rest of the foam packaging material from around the laser tube, the
viewing window, and the rest of the machine.
The laser tube is a highly fragile object and should be handled delicately and as little as possible.
29
