A Graphic Display Area
Parameter Display Area
B
C Coordinate Display Area
D Layer Display Area
E Progress Bar
F System Status
Batch Process Number
G
H File Dimensions
I Network Status
Traces the processed file image during file preview display and
processing.
Displays the file number, speed, and maximum power of the
current processing file.
Displays the coordinate values of the current position of the
laser head.
Displays the layer parameters of the current processing file or the
layer parameters of the preview file. The parameters from left to
right are layer, color, layer speed, and layer maximum power.
Displays the current processing progress.
Displays the current working status of the system, which
are idle, paused, completed, or running. The working time is
displayed on the right.
Displays the processed quantity of the current processing file.
Displays the dimensions of the current file.
Displays the status of the connection to the Internet. When
the network connection is successful, connect is displayed.
Otherwise, Lan OFF is displayed. Usually, you do not need an
internet connection to use this machine.
When the system is running or paused, some buttons on the
control panel will not work, for example, Origin and Frame.
When the system is idle or the work is finished, all the buttons
can be used. For example, you can process the file, set the
parameters, preview your file, and so on.
