• Use only the hardware, wiring, and power sources that came with or are
compatible with this machine. Installing equipment that your machine is not
designed to work with can lead to poor performance, shortened service time,
increased maintenance costs, property damage, and personal injury.
• Note the specific requirements of your system's installation. Every customer
must understand these notes before installation to execute a proper setup
and achieve safe laser performance. If you have any installation questions or
problems, contact our technicians and customer support team.
• Users can configure additional accessories (such as an industrial water chiller,
fume extractor, or rotary axis) to suit needs. Any auxiliary equipment must
be adjusted to the base machine. Queries may be directed to the dealer or
manufacturer of such equipment.

3.1 Selecting a Location

The location should meet all of the following requirements:
• The location meets all of the requirements mentioned in
• The location should be stable, level, dry, and climate-controlled to ensure an ambient
temperature of 40 ℉ –95 ℉ and an ambient humidity under 70%. In particular, the temperature
and humidity together should not be close to the dew point.
• The location should be free of dust and other airborne pollutants and well-ventilated enough to
process any fumes produced by the engraving process in accordance with all applicable laws
and regulations.
• Depending on the materials to be processed, this may require the construction of a dedicated
ventilation system.
• The location should be away from children; combustible, flammable, explosive, or corrosive
materials; and sensitive EMI machines.
• The main power cable should be plugged into a compatible and stable power source via a
grounded 3-prong outlet. No other item should be drawing current from the same fuse.
• The location has fire-fighting equipment nearby and the local fire department's phone number
clearly displayed.
• It is recommended to use a windowless room or to use blinds and/or curtains to avoid exposure
to the potential additional heat of direct sunlight.
• It is highly recommended to have an extra work table nearby to avoid placing objects on or
directly adjacent to the machine, which could become a fire or laser hazard.
§ 1 Safety Information
28
on Page 1.
