5.4.6 Adjusting the Laser Pulse Mode

When Laser Set+ is selected, press
and the display will show:
The operation method is the same as the
previous setting. When Continue is selected,
press to fire the laser, and release the key
to finish firing. When Manual is selected, pushing
will fire the laser for precisely the period
shown beside Laser Set in this screen.

5.4.7 Setting the Origin

When Origin Set+ is selected, press and the display will show:
Press to select an item. When Multi Origin
Enable is selected, press
to enable or disable
the item. When enabled, the small box will be red
and, when disabled, the small box will be gray.
When selecting Set Origin or Next Origin, push
or to select the value. When changing
the parameters of Set Origin, press to
validate the change. Parameters will be saved
automatically when the interface is closed.
