Omtech SH-G570 User Manual page 23

A Cover
Viewing Window
B
C X-Axis Rail
D Y-Axis Rail
E Laser Head
F Workbed
Workbed Adjustment
G
Knob
H Emergency Stop
I Control Panel
J Control System Power
K Laser Lock
L Pass-Through Door
M Front Access Door
Feet
N
O Caster Wheels
Provides access to the main bay for placing and retrieving
materials, as well as fixing the laser path alignment and other
maintenance. Power to the laser is automatically cut when the
cover is opened.
Protects you and others from the laser and its reflection, allowing
monitoring of the engraving process. However, you should never
stare continuously at the laser during operation, even through the
window.
Holds the 2nd mirror and LED lighting, supports the movement of
the laser head left and right across the workbed.
Supports the movement of the X-axis rail up and down across the
workbed.
Holds the 3rd mirror, the focus lens, red dot pointer, and the air
assist outlet.
Can be adjusted in height to fit thinner and thicker materials, as
well as adjusted between the aluminum and honeycomb workbeds.
Allows manual raising and lowering of the workbed along the Z-axis.
Stops the machine instantly by pressing it down in an event of
emergency. Turning it clockwise releases the button.
Provides hands-on control of the engraving process, including
manual movement of the laser head and firing of the laser.
Turns on your engraver's control system, exhaust fan, LED light,
motorized Z axis, and cabinet sockets. Turn it on before the laser
key and turn it off after.
Controls the laser power supply to your laser tube by using the laser
keys. Turn it on after the control system power and turn it off before.
Opens to allow larger pieces of material to be fed through the
workbed. Additional care must be taken to avoid seeing or suffering
exposure to the laser beam and its reflection, and avoid the heavy
material falling down to your feet when taking it out.
Provides access to the area below the workbed for easy cleanup.
Can be rotated down to help anchor the machine in place.
Help move the machine into place.
16
