Font Card; Compactflash Protection Plate; Rfid Kit; Special Printheads - Intermec EasyCoder PM4i User Manual

Font Card

This is a CompactFlash memory card loaded with fonts. With a Font
Card installed, the user gets access to double-byte font sets including
Kanji, Korean and Chinese.

CompactFlash Protection Plate

The protection plate encloses an inserted CompactFlash card and makes
it more difficult to steal. See Chapter 3 for illustration. Can be installed
by the operator.

RFID Kit

The EasyCoder PM4i can be equipped with the capability to read and
write data to labels fitted with RFID (Radio Frequency IDentification)
inlays. RFID Kits come either factory installed or as a field-installable
option.

Special Printheads

As standard, the printer is fitted with an 8 dots/mm (203.2 dots/inch)
thermal printhead. There are also a number of optional printheads for
special applications. The printhead can easily be replaced or exchanged
by the operator as described in Chapter 11.
8 dots/mm (203.2 dots per inch)
Media Thickness
Max 175 µm (7 mils)
170-220 µm (6.6-8.7 mils)
170-220 µm (6.6-8.7 mils) 3mm offset
11.81 dots/mm (300 dots per inch)
Media Thickness
Max 175 µm (7 mils)
170-220 µm (6.6-8.7 mils)

Interface Boards

A number of interface boards are available for use with the EasyCoder
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
Standard/Option
Standard
Option
Option
Standard/Option
Option
Option
Chapter —Options
