Installing Or Replacing The Support Rails: 2076-92F; Removing The 2076-92F Cover - IBM Storwize V7000 Gen2+ Quick Installation Manual

Figure 35. Removing the 2076-92F cover
5. Place the cover in a safe location.
Replace the cover
6. To reinstall the cover, or replace it with one from FRU stock, follow the

Installing or replacing the support rails: 2076-92F

You must install the support rails before you can install a 2076-92F expansion
enclosure in a rack.
Procedure
1. Locate the hardware that is used to install the rails, including the M4xL6 and
Figure 36. Support rails
48
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
procedure in "Installing or replacing the top cover: 2076-92F" on page 65.
M5xL13 screws. Set the hardware, which is shown in Figure 36, aside for use
later in the installation process.
