Figure 83. Fan module orientation
2. Carefully insert the fan module into the chassis until it clicks in place, as shown
Replacing all fan modules
Figure 84. Replace fan module
3. Repeat steps 1 on page 85 and 2 for each fan module to be replaced.
4. Power on the expansion enclosure.

Installing or replacing a fan interface board: 2076-92F

You can replace a fan interface board (FIB) in a 2076-92F expansion enclosure.
Before you begin
This task assumes that the following conditions are met:
v You removed the fan interface board, following the process described in
v All power cables were removed from the enclosure, as described in "Powering
86
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
in Figure 84.
"Removing a fan interface board: 2076-92F" on page 110.
off the expansion enclosure: 2076-92F" on page 129.
