v Always use a suitably rated mechanical lift or four persons when you are
v At least three persons are required to move the enclosure while it is in the rack
v To maximize rack stability, always install the expansion enclosure in the lowest
Weight of expansion enclosure parts
Table 8 summarizes the weight and quantity of the parts (FRUs) that are shipped
with the 5U expansion enclosure.
Table 8. Weight of expansion enclosure parts
FRU FRU part
description number
Enclosure FRU 01LJ607
(replaces
enclosure FRU
P/N 01LJ112)
Rail kit 01LJ114
Front fascia 01LJ116
(4U front
cover)
Display panel 01LJ118
assembly
PSU fascia (1U 01LJ120
cover)
Power supply 01LJ122
unit (PSU)
Secondary 01LJ860 (for
expansion use with
module enclosure FRU
P/N 01LJ607)
01LJ124 (for
use with
enclosure FRU
P/N 01LJ112)
Fan module 01LJ126
Expansion 01LJ128
canister
Cable 01LJ130
management
arm (lower
and upper
arms)
36
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
performing any of the following tasks:
– Removing the expansion enclosure from its packing material
– Lifting and installing the expansion enclosure in the rack for the first time
– Reinstalling the expansion enclosure after you complete a service task (for
example, replacing the enclosure FRU).
(if you are moving the enclosure off the rails). Even after the drives, power
supply units, secondary expander modules, canisters, fans, and top cover are
removed, the enclosure weighs approximately 43 kg (95 lbs).
possible position in the rack.
Weight per unit
kg
42.5
9.231
0.303
0.020
0.010
3.335
0.826
0.890
1.588
1.373
Quantity
shipped
lbs
93.696 1
20.351 1
0.668 1
0.044 1
0.022 1
7.352 2
1.821 2
1.962 4
3.501 2
3.027 1
Total weight
kg lb
42.500 93.696
9.231 20.351
0.303 0.668
0.020 0.044
0.010 0.022
6.670 14.705
1.652 3.642
3.560 7.848
3.176 7.002
1.373 3.027
