7. To reinstall an expansion canister, or replace it with one from FRU stock, follow

Removing a fan module: 2076-92F

You can remove a faulty fan module from a 2076-92F expansion enclosure.
Before you begin
Important: You can remove a fan module without powering off the expansion
enclosure. However, to maintain operating temperature, do not remove more than
one fan module at a time.
v Remove a faulty fan module only when its replacement is ready to be installed.
v Do not remove a fan module from an operational enclosure for more than
About this task
Note: If you plan to remove the expansion enclosure from the rack, you must
remove all of the fan modules.
Procedure
1. Identify the fan module to be replaced. When lit, the amber LED on the front of
Figure 102. Fan module LED
2. Press the release tab on the fan module, as Figure 103 on page 110 shows.
the procedure in "Installing or replacing an expansion canister: 2076-92F" on
page 54.
approximately 10 minutes. The reduction in airflow through the enclosure might
cause the enclosure or its components to shut down to protect from overheating.
the fan module ( 1 in Figure 102) identifies a fault.
1
You can also issue the lsenclosurefanmodule command to display the status of
the fan modules.
Chapter 2. Installing the system hardware
109
