Weight increases as FRUs are installed
The 5U expansion enclosure supports up to 92 SAS drives. As Table 10 shows,
substantial weight is added to the enclosure when all drives are installed.
Table 10. Weight of an enclosure with 92 SAS drives
Approximate weigh per unit
FRU description
2.5-inch tier 0
flash drive
2.5-inch tier 1
flash drive
2.5-inch hard disk
drive
3.5-inch
Near-Line SAS
hard disk drive
As you install or replace FRUs, the overall weight of the expansion enclosure
increases. For example, Table 11 shows the weight progression as different
combinations of FRUs are installed.
Table 11. Enclosure weight as FRUs are installed
Enclosure assembly
FRUs installed
v Enclosure (01LJ607 or
01LJ112)
v Enclosure (01LJ607 or
01LJ112)
v Secondary expansion
modules
38
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
kg lb
0.224 0.494
0.304 0.670
0.876 1.931
FRUs not installed
v Secondary expansion
modules
v Fascia (1U and 4U)
v PSUs
v Expansion canisters
v Fan modules
v Fan interface board
v Display assembly
v Drives
v Cover
v Fascia (1U and 4U)
v PSUs
v Expansion canisters
v Fan modules
v Fan interface board
v Display assembly
v Drives
v Cover
Approximate extra weight
Maximum
supported
kg
92 20.608
92 27.968
92 80.592
Approximate weight
kg
42.5
44.3
lb
45.433
61.659
177.675
lb
93.7
97.7
