1 2 3
Figure 100. Expansion canister
Procedure
1. Read all safety information.
2. Locate the expansion canister to be removed.
3. Release the lower cable management arm to swing it out of the way, as
4. Remove the SAS cables from the expansion canister, as described in "Removing
5. Rotate the handles on the expansion canister outward, as shown in Figure 101.
Figure 101. Removing the expansion canister
6. Carefully pull the expansion canister out of the chassis and place it on a safe,
Replace the expansion canister
108
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
4 5 6
1 Canister fault indicator
2 Canister status
3 Canister power indicator
4 and 6 SAS link fault indicators
5 and 7 SAS link operational indicators
8 Canister release handles
described in "Moving the cable management arms" on page 58.
and installing a SAS cable: 2076-92F" on page 82.
level surface.
7
