Figure 77. Fascia components on the expansion enclosure
Procedure
1. Use the slide rails to pull the enclosure out of the rack, as described in
Remove the front (4U) fascia
2. Remove the front fascia by removing the two screws that attach the fascia to
80
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
"Removing an expansion enclosure from a rack: 2076-92F" on page 89. Ensure
that a mechanical lift is available to support the weight of the enclosure.
the flange on each side of the chassis, as shown in Figure 78 on page 81.
x4
