Features On The Front Of The 2076-92F - IBM Storwize V7000 Gen2+ Quick Installation Manual

v To support the 2076-92F expansion enclosure, a Storwize V7000 Gen2 or
v Before you connect the power cables to the rear of the enclosure, always check
About this task
The 2076-92F expansion enclosure has two power supply units (PSUs) that are
accessible from the front of the enclosure ( 4 in Figure 119). As the figure also
shows, the PSUs are covered by the 1U fascia ( 5 ).
6
2
5
Figure 119. Features on the front of the 2076-92F expansion enclosure
Each PSU has a power supply connector and power cable, which are accessible
from the back of the enclosure. Power is provided by plugging a C19-C20 power
cable into each power supply unit and, if necessary, turning on the power source.
The expansion enclosure does not have a power button.
Procedure
1. Connect the C19-C20 power cables to the power connectors on the rear of the
126
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
Storwize V7000 Gen2+ system requires software version 7.8.0. If software version
7.8.0 is not installed on the system, do not connect or power on the expansion
enclosure.
The Storwize V7000 2076-724 control enclosure (Gen3) requires software version
8.2.0 at the latest available fix level or later. If software version 8.2.0.x is not
installed on the system, do not connect or power on the expansion enclosure.
that the expansion enclosure is secured in the rack. If needed, tighten the
thumbscrews on the front of the enclosure ( 2 in Figure 119) to ensure that the
enclosure drawer does not roll open.
4
1 Display panel LEDs
2 Rack retention thumb screws
3 Power supply unit LEDs
4 Power supply units (PSUs)
5 PSU fascia (1U)
6 Front fascia (4U)
expansion enclosure. The enclosure automatically powers on and begins its
Power On Self-Tests (POST).
3
1
2
