Connectors For The Cable Management Arm; Install The Inner Connector Of The Upper Cma - IBM Storwize V7000 Gen2+ Quick Installation Manual

2
1
4
3
Figure 55. Connectors for the cable management arm
2. Install the inner connector of the upper CMA assembly ( 1 ) to the inner
4
1
2
Figure 56. Install the inner connector of the upper CMA to the inner member of the support rail
3. Install the outer connector of the upper CMA assembly ( 3 ) to the outer
62
Storwize V7000 Gen2 and Gen2+: Quick Installation Guide
1 Inner connector on upper CMA
2 Connector base on inner rail member
3 Outer connector on upper CMA
4 Connector base on outer rail member
5 Support rail connector on upper CMA
6 Connector base on outer rail member
member of the left support rail ( 2 ), as shown in Figure 56.
member of the left support rail ( 4 ), as shown in Figure 57 on page 63.
6
5
