Figure 47. Connectors for the upper cable management arm
1. Press the latch on the connector base on the upper CMA assembly ( 5 in
2.
3. Press the latch on the outer connector of the upper CMA assembly ( 3 in
4. Remove the outer connector from the inner member of the left support rail ( 4
5. Remove the inner connector of the upper CMA assembly ( 1 ) from the inner
Remove the lower CMA assembly
Note: The procedure for removing the lower CMA assembly is the same as the
procedure to remove the upper CMA assembly. However, the connector locations
are reversed. For example, the connector base of the upper CMA ( 5 in Figure 47)
connects to the right rail. The connector base of the lower CMA ( 11 in Figure 48
on page 58) attaches to the left rail.
1 Inner connector on the upper CMA
2 Connector base on inner rail member
3 Outer connector on the upper CMA
4 Connector base on outer rail member
5 Support rail connector on the upper CMA
6 Connector base on outer rail member
Figure 47).
Pull the connector to remove it from the connector base on the right support
rail ( 6 in Figure 47).
Figure 47).
in Figure 47).
member of the left support rail ( 2 ), as shown in Figure 47.
6
5
