2. Service Procedures
Replacing the Z-axis Slave Controller
Step
4.
Replace the slave controller and re-attach the harness.
5.
Set the jumpers correctly for the address and termination.
6.
Replace the curved rear cover.
Recalibrate the robot.
7.
8.
35
PreciseFlex™ Direct Drive Robots - Service Manual
Action
Copyright © 2024, Brooks Automation
Part Number: 628651 Rev. A
