Replacing the Z Column Stage Two Timing Belt

               Electrical Shock
Before replacing the power supplies, the AC power should be removed.
Tools Required
2.0 mm hex driver
l
3.0 mm hex L wrench
l
3.0 mm hex driver
l
4.0 mm ball end hex driver
l
Spare Parts Required
J2 Stage One Belt, PN PFD0-MC-X0006 (500 mm, 1000 mm, 1420 mm stroke)
l
Table 2-10: Replacing the Z Column Stage Two Timing Belt
Step
Move the Z carriage to 640 mm height for the 1000 mm and 1420 mm Z travel robots, or 380 mm
1.
height for the 500 mm Z travel robot.
2.
Turn off the robot power and remove the AC power cord.
