Displays and Cameras

Connecting Monitors and Projectors

Connecting Monitors to Set-Top Systems

If you have a set-top or component system, you need to connect a monitor to
the system to see the people at the far site. Refer to your system's setup sheet
for connection details. The following table shows the different ways you can
connect monitors to a VSX system. The main monitor is the monitor that
displays the VSX system user interface.
VSX System
VSX 5000, VSX 6000A, VSX 7000s,
VSX 7000e, VSX 8000
VSX 5000, VSX 6000A, VSX 7000s,
VSX 7000e, VSX 8000
VSX 5000, VSX 6000A, VSX 7000s,
VSX 7000e, VSX 8000
VSX 5000, VSX 6000A, VSX 7000s,
VSX 7000e, VSX 8000

Additional TV Monitor

The set-top systems provide a second S-Video output for a TV monitor.
Because of their screen resolution, TV monitors are best for showing people
and for playing recorded material from VCR or DVD players.

VGA Monitor or Projector

The set-top systems provide a VGA output for a computer monitor or
projector.
Because of their screen resolution, VGA monitors and projectors are best for
showing content from computers.
Main Monitor Second Monitor
TV (NTSC or PAL) None
TV (NTSC or PAL) TV (NTSC or PAL)
TV (NTSC or PAL) VGA monitor
VGA monitor Not available
