A.2.10.1 AC model
NOMINAL
ABSOLUTE MAXIMUM
FREQUENCY
MAXIMUM POWER
CONNECTOR
A.2.10.2 DC model
NOMINAL
ABSOLUTE MAXIMUM
MAXIMUM POWER
CONNECTOR
A.2.10.3 MR model
NOMINAL
ABSOLUTE MAXIMUM
FREQUENCY
MAXIMUM POWER
CONNECTOR
A.2.11 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.2.12 Environmental specifications
TEMPERATURE RANGE
RELATIVE HUMIDITY
Regesta Smart PRO
110-240 V AC.
85-264 V AC.
50-60 Hz
10 W
2-pole 5.08 mm pitch terminal block .
12-72 V DC
9 - 80 V DC
10 W
2-pole 5.08 mm pitch terminal block.
110-240 V AC
48-72 V DC
85-264 V AC
40 - 85 V DC
50-60 Hz (AC)
10 W
2-pole 5.08 mm pitch terminal block.
Plastic ruggedized casing with optional DIN rail mount.
140 x 80 x 190 mm.
1 Kg.
OPERATION: -20 ºC to +70 ºC
STORAGE: -25º to +70 ºC
5 % to 93 %
