Technical Information
Bandwidth
Antenna
A.5.7 USB 3.0 interface
TERMINAL
CONNECTOR
A.5.8 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.5.9 Power supply
INPUT VOLTAGE
INPUT CURRENT
CONNECTOR
A.5.10 Dimensions and weight
TYPE
DIMENSION
WEIGHT
A.5.11 Environmental specifications
TEMPERATURE
RELATIVE HUMIDITY
36
802.11n: 20/40 MHz
802.11ac: 20/40/80 MHz
802.11ax: 20/40/80 MHz
Integrated directional dual-band MIMO array
Two USB 3.0 (Super Speed) host ports.
Type-A.
RS-232 9600-8-N-1 without flow control.
RJ45 female on the rear panel.
+12V DC.
3 A.
Jack 5.5/2.5 mm.
Desktop / chassis for a 1 U high Rack mount enclosure.
232.8mm X 183.2mm X 45.2mm (excluding LTE antenna)
0.6 Kg
OPERATING NORMALLY: 0 ºC to 40 ºC.
STORED: -25 ºC to 70 ºC.
10 % to 95 %.
Teldat S.A.
Teldat Connect-FW5G
