A.5.4 WAN SFP interface
STANDARDS
SPEED
TYPES
CONNECTOR
A.5.5 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.5.6 Power supply
INPUT VOLTAGE
INPUT CURRENT
CONNECTOR
A.5.7 Dimensions and weight
TYPE
DIMENSION
WEIGHT
A.5.8 Environmental specifications
TEMPERATURE
RELATIVE HUMIDITY
NOISE
RS300 Series
802.1Q (VLAN).
1000-Base-X.
MSA and SFF 8472 compliant.
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
Standard SFP connector.
RS-232 115200-8-N-1 without flow control.
RJ45 female on the rear panel.
+12V DC.
2.5 A.
Jack 5.5/2.5 mm.
Desktop / chassis for a 1 U high Rack mount enclosure.
283mm x 144mm x 40mm
0.6 Kg
OPERATING NORMALLY: 0 ºC to 45 ºC.
STORED: -25 ºC to 70 ºC.
10 % to 95 %.
38.3 dB SPL (5000 rpm).
