Radio Information

Appendix B Radio Information

B.1 RF WWAN specifications
The Regesta Smart PRO model, equipped with the EC25 module, offers network connectivity across multiple radio
frequency bands, in line with the latest 3GPP Standards.
• LTE (3GPP Release 10),
• DC-HSPA+ (3GPP Release 8),
• HSPA+ (3GPP Release 7),
• HSUPA (3GPP Release 6),
• HSDPA (3GPP Release 5),
• and GSM, GPRS, EDGE (3GPP Release 99 with Feature Package#1).
Please note that this product does not come with antennas included. The operator has the freedom to select suitable
antennas, but it is their responsibility to ensure compliance with local regulations.
Technology: LTE EC25-E specifications.
Bands
Band 1
Band 3
Band 5
Band 7
Band 20
Technology: LTE EC25-AU specifications.
Bands
Band 4
Band 5
Band 7
Band 28
42
Frequencies
Tx: 1920-1980 MHz
Rx: 2110-2170 MHz
Tx: 1710–1785 MHz
Rx: 1805–1880 MHz
Tx: 824-849 MHz
Rx: 869-894 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 832–862 MHz
Rx: 791–821 MHz
Frequencies
Tx: 1710–1755 MHz
Rx: 2110–2155 MHz
Tx: 824–849 MHz
Rx: 869–894 MHz
Tx: 2500–2570 MHz
Rx: 2620–2690 MHz
Tx: 703–748 MHz
Rx: 758–803 MHz
Conducted Transmit Power
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 1 dB
Conducted Transmit Power
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
+23 dBm ± 2 dB
