Technical Information
A.5.4 WAN SFP interface
STANDARDS
SPEED
TYPES
CONNECTOR
A.5.5 USB interface
SPEED
CONNECTOR
A.5.6 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.5.7 Power supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
A.5.8 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.5.9 Environmental specifications
TEMPERATURE
RELATIVE HUMIDITY
18
802.1Q (VLAN).
1000-Base-X.
1000 Mbps full duplex.
LX/LH (single-mode 1310 nm).
SX (multi-mode 850 nm).
ZX (single-mode 1550 nm).
Standard SFP connector.
The interface complies with the USB 2.0 (480 Mbps) standard; the end speed de-
pends on the 3G USB modem used.
USB Type A.
RS-232 9600-8-N-1 without flow control.
RJ45 female on the device's front panel.
100-240 V AC
0.9 A
50/60 Hz
30 W
Desktop / chassis for a 1 U high Rack mount enclosure.
313 x 483 x 43.6 mm.
4.1 kg.
OPERATING NORMALLY: 0 ºC to 40 ºC
On: 5 % to 90 %
