Power Supply; Dimensions And Weight; Environmental Specifications - Teldat WWAN Enabler Installation Manual

Teldat S.A.
A.4.5 Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
A.4.6 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.4.7 Environmental Specifications
TEMPERATURE
RELATIVE HUMIDITY
WWAN Enabler
+12 V DC.
1.6 A.
5.5 mm.
2.5 mm.
Desktop or wall-mounted.
196.33 x 196.33 x 54.93 mm.
0.4 kg.
OPERATING NORMALLY: 0 ºC to 45 ºC
STORED: -25 ºC to 70 ºC
On: 5 % to 90 %
Technical Information
33
