Technical Information
A.5.2 Eth RJ45 interface
PROTOCOLS
PORTS
SPEED
CONNECTOR
A.5.3 Eth SFP/SFP+ interface
STANDARDS
SPEED
CONNECTOR
A.5.4 USB 3.0 interface
TERMINAL
CONNECTOR
A.5.5 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.5.6 Power supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
MAXIMUM POWER
A.5.7 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
18
Ethernet (802.3).
8-port Switch managed with MDI/MDX autodetection.
10/100/1000 Mbps (Base-T).
RJ45 female.
802.1Q (VLAN).
1000-Base-X.
1/10 Gbps full duplex.
Standard SFP/SFP+ connector.
Two USB 3.0 (Super Speed) host ports.
Type-A.
RS-232 115200-8-N-1 without flow control.
RJ45 female on the device's front panel.
100-240 V AC
2 A
50/60 Hz
200 W
Desktop / chassis for a 1 U high Rack mount enclosure.
315 x 444 x 44 mm
315 x 483 x 44 mm (with backets)
4 kg.
Teldat S.A.
Teldat Edge Router RXL15000
