Technical Information
CONNECTOR
SIM Slot
ANTENNA
A.4.3.1 Antenna connectors
Antenna connectors
Connector
A.4.4 Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
A.4.5 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.4.6 Environmental Specifications
TEMPERATURE
RELATIVE HUMIDITY
30
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Two SMA connectors
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
Devices equipped with this interface are shipped with two multi-band swivel-mount
dipole antennas.
ANT4 ANT3
Diversity (RX)
+12 V DC.
1.6 A.
5.5 mm.
2.5 mm.
Desktop or wall-mounted.
196.33 x 196.33 x 54.93 mm.
0.4 kg.
OPERATING NORMALLY: 0 ºC to 45 ºC
STORED: -25 ºC to 70 ºC
On: 5 % to 90 %
ANT2 ANT1
Main (TX/RX)
