Technical Information
A.2.6 Wireless WAN interface
WWAN Standard/Bands
Speed (DL/UL)
CONNECTOR
SIM Slots
A.2.7 Configuration interface
LOCAL TERMINAL
CONNECTOR
A.2.8 RS-232 serial interface
STANDARDS
SPEED
CONNECTOR
A.2.9 RS-485 serial interface
STANDARDS
SPEED
CONNECTOR
A.2.10 Power supply specifications
40
EC25-E:
• LTE:
• FDD. B1, B3, B5, B7, B8, B20
• TDD: B38, B40, B41
• WCDMA: B1, B5, B8
• GSM/GPRS/EDGE: 900/1800 MHz
EC25-AU:
• LTE:
• FDD. B4, B5, B7, B28
• WCDMA: B2, B5
• GSM/GPRS/EDGE: 850/1900 MHz
• LTE Cat 4.
• FDD. 150Mbps/50Mbps
• TDD: 130Mbps/35Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
• UMTS: 384Kbps/384kbps
• EDGE: 236Kbps/236Kbps
• GPRS: 85.6Kbps/85.6Kbps
Two RF SMA female connectors. (Optional).
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
V.24 115200-8-N-1-without flow control.
RJ-45 female on the connector panel.
RS-232. Asynchronous serial port with control signals.
From 300 to 115200 bps.
RJ-45 female on the connector panel (optional).
2-4 wire RS-485/RS-422 configurable via software. Bus termination configurable
via software.
From 300 to 115200 bps.
RJ-45 female on the connector panel (optional).
