A.5.3 Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
A.5.4 Configuration Interface
LOCAL TERMINAL
CONNECTOR
A.5.5 Direct Power Supply
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
A.5.6 Alternating Power Supply
INPUT VOLTAGE
INPUT FREQUENCY
MAXIMUM POWER
A.5.7 Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
A.5.8 Environmental Specifications
AMBIENT TEMPERATURE
Regesta-PRO-ER
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depends on the device's wire-
less WAN version.
Depends on the device's wireless WAN version. Please see the manual on the ap-
propriate module.
RF SMA female
Depends on the type of wireless WAN. Please see the catalog on the antennas for
cellular interfaces.
V.24 9600-8-N-1 without flow control
DB9 female on the front panel of the device.
-48 V DC
300 mA
15 W
220 V AC
50 Hz
23.3 VA / Factor 0.6 / 14 W
Ruggedized casing that allows for DIN rail mount support
Without protector:
230 x 186 x 50 mm
With protector:
270 x 186 x 50 mm
650 gr
ON: -10 °C to +60 °C
OFF: -25 °C to +60 °C
Technical Information
