A.4.6 RS-485 Serial Port Connectors
DB9
A.5 Technical Specifications
A.5.1 LAN Interface
PROTOCOLS
SPEED
CONNECTOR
A.5.2 DSL Interface
STANDARDS
SPEED
CONNECTOR
A.5.3 Wireless WAN Interface
STANDARDS
SPEED
CONNECTOR
ANTENNA
Regesta-PRO ER B Router
PIN
1
2
3
4
5
6
7
8
9
Ethernet (802.3).
Switch 10/100 Mbps (Base T).
RJ45 female.
Not available.
Not available.
Not available.
GPRS, UMTS, HSDPA, HSUPA, HSPA+, LTE ... Depends on the device wireless
WAN version.
Depends on the device wireless WAN version. Please see the manual on the rel-
evant module.
RF SMA female (optional).
Depends on the type of wireless WAN. Please see the catalog on the antennas for
cellular interfaces.
SERIAL
--
4H_RX+
2H_R/TX+_4H_TX+
--
GND
4H_RX-
--
--
2H_R/TX-_4H_TX-
Technical Information
21
