A.4.3 Wireless WAN interface
WWAN Standard/Bands
Speed (DL/UL)
CONNECTOR
SIM Slots
ANTENNA
A.4.4 Wireless LAN interface
Note: 802.11ac features only available on 802.11ac capable devices.
WLAN standards
Frequency bands 2.4 GHz in-
door/outdoor (EU)
Frequency bands 5 GHz indoor
(EU)
Frequency bands 5 GHz out-
door (EU)
WLAN modes
2.4 GHz Operation
WLAN modes
Teldat H2 RAIL
MC7455:
• LTE:
• FDD. B1-B5, B7, B12, B13, B17, B20, B25, B26, B29, B30
• TDD: B41
• WCDMA: B1, B2, B3, B4, B5, B8
MC7430:
• LTE:
• FDD. B1, B3, B5, B7, B8, B18, B19, B21, B28
• TDD: B38-B41
• WCDMA: B1, B5, B6, B8, B9, B19
• TD-SCDMA: B39
MC7455:
• LTE Cat 6.
• FDD. 300Mbps/50Mbps
• TDD: 222Mbps/26Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
MC7430:
• LTE Cat 6.
• FDD. 300Mbps/50Mbps
• TDD: 222Mbps/26Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Up to eight N coaxial connectors.
4 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
The antennas are supplied separately from the device.
802.11b; 802.11g; 802.11n (Mimo 2x2); 802.11a and 802.11ac (Mimo 2x2).
2.4 GHz Indoor/Outdoor (2412-2484 MHz) max. 100 mW EiRP.
5 GHz indoor (5150-5350 MHz) max. 200 mW EiRP allowed.
5 GHz outdoor (5470-5725 MHz).
802.11b only; 802.11g only, 802.11b/g/n mixed; 802.11b/g/n mixed long;
802.11b/g/b mixed short; 802.11b/g/n ; 802.11g/n; 802.11n only
801.1a only; 802.11a/n; 802.11n only; 802.11ac with up to 867 Mbit/s.
Technical information
