A.5.5 Wireless WAN interface
WWAN Standard/Bands
Speed (DL/UL)
Teldat Connect-FW5G
RM520N-GL:
• 5G-NR (Sub-6GHz):
• 3GPP Release 16 (NSA and SA modes)
• NSA bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n20, n25, n26, n28, n29,
n30, n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79
• SA bands: n1, n2, n3, n5, n7, n8, n12, n13, n14, n20, n25, n26, n28, n29, n30,
n38, n40, n41, n48, n66, n71, n75, n76, n77, n78, n79
• Network Options: Option 2 for SA and Option 3/3a/3x for NSA EN-DC. DSS
supported in all FDD bands
• EN-DC Combinations: Up to 5DL + 1FR1 and 2DL + 2FR1.
• UL modulation: 256QAM for FR1.
• DL modulation: 256QAM for FR1.
• SA UL 2 × 2 MIMO: n38, n41, n48, n77, n78, n79
• DL MIMO:
• DL 2 x 2 MIMO are supported on all bands
• SA DL 4 × 4 MIMO: n1, n2, n3, n7, n25, n30, n38, n40, n41, n48, n66, n70,
n77, n78, n79
• NSA DL 4 × 4 MIMO: n1, n2, n3, n7, n25, n30, n66, n38, n40, n41, n48,
n70, n77, n78, n79
• Subcarrier Spacing (SCS) modes: FDD can only support 15KHz, and TDD can
only support 30KHz.
• BW per CC: Up to 100MHz.
• LTE:
• 3GPP Release 16
• FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B14, B17, B18, B19, B20, B25,
B26, B28, B29, B30, B32, B66, B71
• TDD: B34, B38, B39, B40, B41, B42, B43, B48
• LAA: B46
• UL modulation: up to 256QAM.
• DL modulation: up to 256QAM.
• Carrier Aggregation: DL: Up to 5CC, UL: 2CC intra-band continuous and inter-
band CA.
• DL MIMO
• 2x2 DL MIMO are supported on all bands
• 4x4 DL MIMO can be supported on bands B1, B2, B3, B4, B7, B25, B30,
B38, B40, B41, B42, B43, B48, B66
• WCDMA:
• 3GPP Release 8 and Release 99
• B1, B2, B4, B5, B8, B19
The data rates presented are only theoretical, meaning the actual value will de-
pend on the network's condition.
RM520N-GL:
• 5G-NR
• NSA: DL 3.3 Gbps; UL 600 Mbps
• SA: DL 2.4 Gbps; UL 900 Mbps
