A.5.6 Wireless WAN interface
WWAN Standard/Bands
Speed (DL/UL)
CONNECTOR
SIM Slot
ANTENNA
A.5.6.1 Antenna connectors
Antenna connectors
Connector
34
802.11n: 20/40 MHz
802.11ac: 20/40/80 MHz
802.11ax: 20/40/80 MHz
Integrated directional dual-band MIMO array
EM06-E:
• LTE:
• 3GPP Release 11
• FDD. B1, B3, B5, B7, B8, B20, B28, B32
• TDD: B38, B40, B41
• 2xCA :
• B1 + B1/B5/B8/B20/B28;
• B3 + B3/B5/B7/B8/B20/B28;
• B7 + B5/B7/B8/B20/B28;
• B20 + B32;
• B38 + B38;
• B7 + B3/B7/B20;
• B40 + B40;
• B41 + B41
• WCDMA:
• 3GPP Release 9
• B1, B3, B5, B8
The data rates presented are theoretical only, and the actual value depends on
the network's condition.
EM06-E
• LTE Cat 6.
• FDD. 300Mbps/50Mbps
• TDD: 222Mbps/26Mbps
• HSPA+ Cat 24/6: 42Mbps/5.76Mbps
Two SMA connectors
2 Mini-SIM (2FF) ISO/IEC 7810:2003, ID-000 (1.8V / 3V)
Devices equipped with this interface are shipped with two multi-band swivel-mount
dipole antennas.
ANT1 (Left)
Diversity (RX)
ANT2 (Right)
Main (TX/RX)
