Input - Endress+Hauser Proline Promass H 300 PROFINET Operating Instructions Manual

Proline Promass H 300 PROFINET
Measured variable
Measuring range
Endress+Hauser
16.3

Input

Direct measured variables
• Mass flow
• Density
• Temperature
Calculated measured variables
• Volume flow
• Corrected volume flow
• Reference density
Measuring range for liquids
DN
[mm]
8
15
25
40
50
Measuring range for gases
Measuring ranges valid only for Promass H with tantalum 2.5W.
The full scale value depends on the density and the sound velocity of the gas used and can
be calculated with the formula below:
 = minimum (
max(G) max(F)
 Maximum full scale value for gas [kg/h]
max(G)
 Maximum full scale value for liquid [kg/h]
max(F)
 <  
max(G) max(F)
ρ Gas density in [kg/m³] at operating conditions
G
x Constant dependent on nominal diameter
c Sound velocity (gas) [m/s]
G
d Measuring tube internal diameter [m]
i
DN
[mm]
8
15
25
40
50
Measuring range full scale values 
[in]
³⁄₈
½
1
1½
2
· ρ : x ; ρ · c · π/2 · (d
G G G i
can never be greater than 
max(G)
[in]
³⁄₈
½
1
1½
2
Technical data
[kg/h] [lb/min]
0 to 2 000 0 to 73.50
0 to 6 500 0 to 238.9
0 to 18 000 0 to 661.5
0 to 45 000 0 to 1 654
0 to 70 000 0 to 2 573
) 2 · 3600)
max(F)
x
[kg/m 3 ]
60
80
90
90
90
to 
min(F) max(F)
223
