16.10 Mechanical construction

For the dimensions and installation lengths of the device, see the "Technical
Information" document, "Mechanical construction" section.
All values (weight exclusive of packaging material) refer to devices with EN/DIN
PN 40 flanges. Weight specifications including transmitter as per order code for "Housing",
option A "Aluminum, coated".
Different values due to different transmitter versions:
• Transmitter version for the hazardous area
(Order code for "Housing", option A "Aluminum, coated"; Ex d): +2 kg (+4.4 lbs)
• Cast transmitter version, stainless
(Order code for "Housing", option L "Cast, stainless"): +6 kg (+13 lbs)
Weight in SI units
DN
[mm]
8
15
25
40
50
Weight in US units
DN
[in]
3/8
½
1
1½
2
Transmitter housing
Order code for "Housing":
• Option A "Aluminum, coated": aluminum, AlSi10Mg, coated
• Option L "Cast, stainless": cast, stainless steel, 1.4409 (CF3M) similar to 316L
Window material
Order code for "Housing":
• Option A "Aluminum, coated": glass
• Option L "Cast, stainless": glass
Cable entries/cable glands
Proline Promass H 300 PROFINET
Weight [kg]
10
11
17
34
67
Weight [lbs]
22
24
37
75
148
