Proline Promass H 300 PROFINET
Parameter
Switch output function
Assign diagnostic behavior
Assign limit
Assign flow direction check
Assign status
Endress+Hauser
Prerequisite
The Switch option is selected
in the Operating mode
parameter.
• In the Operating mode
parameter, the Switch
option is selected.
• In the Switch output
function parameter, the
Diagnostic behavior option
is selected.
• The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Flow direction check
option is selected in the
Switch output function
parameter.
• The Switch option is
selected in the Operating
mode parameter.
• The Status option is
selected in the Switch
output function parameter.
Description
Select function for switch
output.
Select diagnostic behavior for
switch output.
Select process variable for limit
function.
Select process variable for flow
direction monitoring.
Select device status for switch
output.
Commissioning
Selection / User Factory setting
interface / User
entry
• Off Off
• On
• Diagnostic
behavior
• Limit
• Flow direction
check
• Status
• Alarm Alarm
• Alarm or warning
• Warning
• Mass flow Mass flow
• Volume flow
• Corrected volume
*
flow
*
• Target mass flow
*
• Carrier mass flow
• Target volume
*
flow
• Carrier volume
*
flow
• Target corrected
*
volume flow
• Carrier corrected
*
volume flow
• Density
*
• Reference density
*
• Concentration
• Temperature
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Oscillation
damping
• Pressure
• Application
*
specific output 0
• Application
*
specific output 1
• Index
inhomogeneous
medium
• Index suspended
*
bubbles
• Off Mass flow
• Volume flow
• Mass flow
• Corrected volume
*
flow
• Partially filled pipe Partially filled pipe
detection detection
• Low flow cut off
*
• Profinet Slot 24
*
• Profinet Slot 25
*
• Profinet Slot 26
