Proline Promass H 300 PROFINET
Degree of protection
Vibration- and shock-
resistance
Mechanical load
Electromagnetic
compatibility (EMC)
Medium temperature range
Endress+Hauser
Measuring device
• As standard: IP66/67, type 4X enclosure
• When housing is open: IP20, type 1 enclosure
• Display module: IP20, type 1 enclosure
External WLAN antenna
IP67
Vibration broad-band random, according to IEC 60068-2-6
• 2 to 8.4 Hz, 3.5 mm peak
• 8.4 to 2 000 Hz, 1 g peak
Vibration broad-band random, according to IEC 60068-2-64
• 10 to 200 Hz, 0.003 g
2
• 200 to 2 000 Hz, 0.001 g
• Total: 1.54 g rms
Shock half-sine, according to IEC 60068-2-27
6 ms 30 g
Rough handling shocks, according to IEC 60068-2-31
Never use the transmitter housing as a ladder or climbing aid.
As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21)
Details are provided in the Declaration of Conformity.
16.9
Process
–50 to +205 °C (–58 to +401 °F) for zirconium 702/R 60702
–50 to +150 °C (–58 to +302 °F) for tantalum 2.5 W
/Hz
2
/Hz
Technical data
Order code for "Measuring tube
mat., wetted surface", option DA
Order code for "Measuring tube
mat., wetted surface", option EA
237
